| Type |
GV1 |
| Rated insulated volatge(V) |
660V |
| No.of pole(P) |
3 |
| Rated short circuit Breaking capacity(KA) |
220V |
1.5/0.95 |
| 380V |
1.5/0.95 |
| 660V |
1.0/0.95 |
| Rated short circuit capacity(KA) |
220V |
2.12/0.95 |
| 380V |
2.12/0.95 |
| 660V |
1.41/0.95 |
|
TECHNICAL SPECIFICATION:
| Type |
Spec.(A) |
| GVE～M01 |
0.10～0.16 |
| GVE～M02 |
0.16～0.25 |
| GVE～M03 |
0.25～0.40 |
| GVE～M04 |
0.40～0.63 |
| GVE～M05 |
0.63～1 |
| GVE～M06 |
1～1.6 |
| GVE～M07 |
1.6～2.5 |
| GVE～M08 |
2.5～4 |
| GVE～M10 |
4～6 |
| GVE～M14 |
6～10 |
| GVE～M20 |
10～16 |
| GVE～M21 |
16～20 |
| GVE～M22 |
20～25 |
|
